CI TOOLS for ArchiCAD 26 INT
Archicad 27 Ci Tools Premium (Fix AC27.1.1)
Ci Tools – Archicad 的 Ci 扩展工具，Archicad 不可或缺的工具 – 由建筑师设计和建造，为建筑师服务。
门+窗工具
Ci 门+窗户工具让您可以自由地探索更多种类的门窗样式，包括各种面板、打开方法、装饰和门槛。
为您的设计增添个性，不受风格、复杂性或结构的限制。更重要的是，使用此工具制作的门窗对象可以使用强大的 Ci 预设系统跨项目共享。
主题演讲工具
使用 Ci Keynotes 结束注释 Archicad 图形的乏味和潜在错误。
Keynote 讲演通过提供一个框架来创建注释数据库（或传输现有数据库），以便注释根据元素的属性自动附着到元素，从而使您能够快速、简单地、更准确地注释图形。您可以直接在图形上放置一个没有任何参考的完整注释，或者在图形上放置一个参考关键帧，然后 Keynote 讲演会编译这些注释的明细表。
机柜工具
只需使用一个高度可配置的对象来对所有橱柜进行建模，而不必为每种不同的橱柜类型和形状使用单独的对象。
使用新库，您可以轻松模拟扁平和弯曲的橱柜门和抽屉门。从大量可编辑面板样式和手柄类型中混合搭配，以创建独特的外观。覆盖物工具
通过在 2D 和 3D 视图中将 3D 建模蒙皮应用于墙、楼板、柱和屋顶，为您的 Archicad 模型增添真实感。
此工具将为 Archicad 项目的表面添加深度和细节。表面在 2D、3D、剖面和立面视图中表示，当对象大小更改时，它们甚至会保持正确的比例。创建的曲面保持与主要元素的自动关系，并且每当更新或更改时，附着的 3D 建模对象都会相应地更新。
目标工具
Ci Objective旨在大大提高您在Archicad中进行3D建模的能力，感觉就像环境的自然组成部分。
目标工具现在结合了 Ci 拉伸和板坯边工具的功能。这使它成为一个非常强大的工具，为您提供弯曲、分割、旋转、对齐和修改 Archicad 模型中元素所需的一切。电动工具
使用Ci电气工具，放置电气符号不仅简单，而且智能。只需在放置符号时设置所需的高程，当您单击放置符号时，符号将自动旋转并定位到墙壁上。
电气工具附带一个电源点、开关、插孔和其他墙板库，这些墙板都可以显示为墙板本身或墙板包含的各个组件。
楼梯工具
设计灵活而自由的楼梯，直接进入您的模型。
使用Ci楼梯，您可以访问一系列单独的组件，这些组件允许为住宅和商业设计提供高度灵活的楼梯配置。
栏杆可以与楼梯、平板甚至独立设置相关联，以便楼梯可以轻松地以不同的宽度和高度缠绕并打开平台。楼梯组件可以像单个对象一样进行编辑、标记和输出。
元数据工具
Ci元数据工具允许您在方便的调色板中使用模型元素的属性和分类，而不必跳过对话框来查找所需的内容。
它还使批量更改属性变得更加容易，筛选器和选择选项将帮助您在检查模型时轻松找到要查找的元素。
注释工具
Ci 注释工具可让您在 Archicad 中控制文本大小写 - 您可以将所有文本或仅所选文本更改为全大写、小写、句子大小写或标题大小写。这样就无需重新键入所有内容。
您还可以向文本大小写规则添加例外，甚至可以将更改应用于对象内部的文本。
快捷工具
Ci Shortcut 是一种速度提升工具，可帮助您一键查找和缩放到您在 3D 或剖面/立面中选择的任何模型元素的平面视图表示。
当您在 3D 和剖面/立面中浏览模型以进行检查时，这很有用。找到需要进一步调查的元素后，只需选择它并使用快捷方式在平面图视图中直接跳转到该元素。
变压器工具
Ci 转换器工具是 Archicad 24 中的全新工具，是需要镜像整个项目的客户的一键式解决方案。目前，这样做是一个耗时且容易出错的过程，因为当您仅旋转 3D 模型时，需要额外的工作来镜像和检查所有 2D 工作和其他附加元素。
使用Ci变压器，只需选择要镜像项目的轴，我们的工具将负责其余的工作。您的所有模型元素以及标记、标签和其他 2D 工作都会为您镜像。
数量工具
CI 数量是一种解决方案，用于改进从实时 Archicad 项目模型中计算、调度和导出工程量清单的过程。
您可以将成本和数量分配给您的 Archicad 元素，或使用智能配方自动分配它们，然后随时生成数量清单，选择在 Archicad 中查看账单计划或将其导出以在第三方工具中使用。
站点工具
此工具仅在新西兰和西澳大利亚州可用。
此工具集合提供了一种简单的可视化方法来评估模型与排版、边界和周围建筑物的关系。在设计过程的早期阶段，在探索与场地相关的设计选项时，网站特别有用。它包括面积和区域图章、测量边界工具和建筑围护结构。
详图元素工具
此工具仅在新西兰提供，在澳大利亚面向精选年度客户和高级订阅会员提供。
细节元素通过大量可拖放的智能参数化 2D 对象来消除细节工作。它通过动态编辑它们来节省文档过程的时间，并消除细节的平凡和无聊方面。
框架管理员工具
Ci Framewright工具专门设计用于帮助设计Oak Frame房屋，主要在英国。它不是通用的框架解决方案。在CAD程序中设计橡木框架结构可能特别困难，因为许多组件将具有无法用参数描述的不规则形状。但是，通过将 FrameWright 添加到 Arpicad，您可以将任何用户定义的形状转换为框架对象。
支撑工具
此工具仅在新西兰可用。专为我们的新西兰客户设计，用于根据NZS3604：2011计算木结构建筑墙壁所需的支撑单元。
该工具还会自动添加大括号线，即基于您喜欢的大括号集的物理大括号，并创建一个大括号表。
Ci Tools – Ci extensions for Archicad
Indispensable tools to unleash Archicad – Designed and built by architects, for architects.
Doors+Windows Tool
The Ci Doors+Windows Tool gives you the freedom to explore a greater variety of door and window styles with a variety of panels, opening methods, trims and sills.
Add personality to your designs without restrictions on style, complexity or construction. What’s more, door and window objects made using this tool can be shared across projects, using the powerful Ci Presets system.
Keynotes Tool
End the tedium and potential errors of annotating your Archicad drawings by using Ci Keynotes.
Keynotes allows you to annotate your drawings quickly and simply with greater accuracy by providing a framework to create a database of notes (or to transfer an existing database) so that notes automatically attach to elements based on their attributes.
You can place a full note without any reference directly on a drawing, or place a reference key on the drawing and then Keynotes compiles a schedule of these notes.
Cabinets Tool
Use just one highly-configurable object to model all your cabinetry, instead of having to use separate objects for each different cabinet type and shape.
Using the new library you can easily model flat and curved cupboard doors and drawer fronts. Mix and match from a generous palette of editable panel styles and handle types to create that unique look.
Coverings Tool
Add realism to your Archicad model by applying 3D modelled skins to walls, slabs, columns and roofs in both 2D and 3D views.
This tool will add depth and detail to the surfaces of your Archicad projects. The surfaces are represented in your 2D, 3D, section and elevation views and they even retain their correct proportions when object sizes are changed.
The surfaces created maintain an automatic relationship to the primary elements, and whenever it is updated or changed, the attached 3D modelled objects update correspondingly.
Objective Tool
Ci Objective has been designed to greatly increase your ability to model in 3D in Archicad, in a way which feels like a natural part of the environment.
The Objective tool now combines the functionality of the Ci Extrusions and Slab Edges tools. This makes it an incredibly powerful tool that gives you everything you need to bend, split, rotate, align and modify elements in your Archicad Model.
Electrical Tool
With the Ci Electrical tool, placing electrical symbols is not only simple, but smart too. Just set the elevation you want when you place them, and the symbols will automatically rotate and position themselves to your walls when you click to place them.
The Electrical tool comes with a library of Power Points, Switches, Jacks, and other Wall Plates, which can all be shown as either the Wall Plate itself, or the individual components that Wall Plate contains.
Stairs Tool
Design stairs with flexibility and freedom, straight onto your model.
With Ci Stairs, you have access to a range of individual components that allow for highly flexible stair configurations for both residential and commercial designs.
Railings can be associated with stairs, slabs or even stand-alone, so that stairs can easily wind at varied widths and heights and open on to landings. Stair assemblies can be edited, labelled and output as if they were a single object.
Metadata tool
The Ci Metadata tool allows you to work with the Properties and Classifications of your model elements in a handy palette, instead of having to jump through dialog boxes to find what you need.
It also makes bulk changes of properties easier, and the filter and selection options will help you simply find the elements you’re looking for as you check your model.
Annotation tool
The Ci Annotate tool lets you take control of your text case in Archicad – you can change all text, or just the selected text to all-caps, lowercase, sentence case, or heading case. This removes the need to retype everything.
You can also add exceptions to your text case rules, and even apply the changes to text inside of objects.
Shortcut tool
Ci Shortcut is a speed-boosting tool to help you find and zoom to the plan view representation of any model elements you select in 3D or Section/Elevation – in one click.
This is useful for when you are exploring your model in 3D and Sections/Elevations to check it . Once you find an element that needs further investigation, just select it and use the Shortcut to jump right to it in your Floorplan view.
Transformer tool
The Ci Transformer tool is brand new in Archicad 24 and is a one-click solution for customers who need to Mirror an entire project. Currently, doing that is a time consuming and error-prone process due to the extra work required to mirror and check on all the 2D work and other attached elements when you rotate just the 3D model.
With Ci Transformer, simply select the Axis you want to mirror your project by, and our tool takes care of the rest . All your model elements, as well as markers, labels, and other 2D work get mirrored for you.
Quantities tool
CI Quantities is a solution for improving the process of calculating, scheduling, and exporting a bill of quantities from a live Archicad project model.
You can assign costs and quantities to your Archicad Elements, or automatically assign them using smart Recipes, and then generate Bills of Quantity at any time as you go, choosing to view the Bill Schedule in Archicad or export it to use in third-party tools.
Sites Tool
This tool is only available in New Zealand and Western Australia.
This collection of tools provides an easy visual way of evaluating your model in relation to typography, boundaries and surrounding buildings. Sites is especially helpful in the early stages of the design process when exploring design options in relation to the site. It includes area and zone stamps, survey boundary tool, and building envelopes.
Detail Elements Tool
This tool is only available in New Zealand, and in Australia for Select Annual customers and Premium Subscription members.
Detail Elements take the work out of detailing with a huge set of smart parametric 2D objects ready to be dragged and dropped. It saves hours from the documentation process by dynamically editing them, and remove the mundane and boring aspects of detailing.
Framewright Tool
The Ci Framewright tool is specifically designed to be used to help design Oak Frame houses, primarily in the UK. It is not a general purpose framing solution. Designing an oak frame construction in a CAD program can be particularly difficult given that many of the components will have irregular shapes that cannot be described parametrically. However, by adding FrameWright to Archicad you can convert any user-defined shape into a framing object.
Bracing tool
This tool is only available in New Zealand. Specifically designed for our NZ Customers to calculate the required bracing units for the walls of your Timber-framed buildings based on NZS3604:2011.
The Tool also automatically adds the Bracing Lines, the physical braces based of your preferred Brace Set along these Brace Lines and creates a Bracing Table.
